High-frequency current sensors can be used to measure and monitor:
Current waveform amplitude from microamperes to megaamperes in high-voltage and low-voltage circuits
High-voltage pulse current, related to microwave or X-ray tube modulators, particle accelerators and lasers
Current transients and harmonics in power systems
Lightning current observation
pulsed charged particle beam current
Research on Broadband Current in Laboratory
High-end medical multi-band current sensing
Current in spot welding machines and induction welding machines
Switch short-circuit current detection
-
Bandwidth
10Hz-20MHz
-
Current
AC 20A RMS
-
Pulse Current
AC 2000A peak
-
Accuracy
±1%
-
Rise time
≤20ns
-
Range sensitivity
100mV/A
-
Input impedance
1MΩ
-
Opening diameter
14mm
-
Cable length
100mm
-
Overall dimension
83.5x60x20mm
-
Weight
380g
-
Temperature and humidity
-20~80°C、less than 80% RH
