ETA5540B Current probe

A current probe detects the current flowing through a conductor and converts it into a voltage that can be seen and measured on an oscilloscope. The current probe uses a mix of technologies including Halleffect sensors (sensing DC current) and current transformers (sensing AC current). The open-ended design current probe is easily connected to and disconnected from the conductor, providing a DC to 100 MHz measurement bandwidth.

• Bandwidth

  DC-50MHz

• Current

  DC/AC peak 40A

• Rise time

  ≤7ns

• Range sensitivity

  50mV/A

• Typical DC Accuracy

  士2%rdg

• Maximum operating voltage

  CATI 400V

• Zero adjustment mode

  Automatic

• Power supply modenction

  5V/2A power supply

• Jaw diameter

  Φ4.5mm

• Interface Type

  BNC

• Weight

  200g

• Overall dimension

  230mmx45.5mmx24.5mm

• Maximum pulse current

  50A(TP≤10uS)

• Noise

  ≤1mVrms

• Linearity

  ±1%

• Delay time

  20ns

• Cable length

  130cm
