Attenuation ratio
10:1 / 1:1
-
Bandwidth
DC to 200MHz
-
Rise time
1.75nS
-
Input impedance
10MΩ / 1MΩ
-
Input capacitance
12 pF / 95 pF
-
Compensation range
10 to 50 pF
-
Input voltage
10:1 400V CAT I, 300V CAT II ；1:1 150V CAT I
-
Temperature and humidity
0℃ to 50 ℃；85% RH
-
Overall length
1.2m
-
-
-
Attenuation ratio
10:1 / 1:1
-
Bandwidth
DC to 300MHz
-
Rise time
1.2nS
-
Input impedance
10MΩ / 1MΩ
-
Input capacitance
12 pF / 95 pF
-
Compensation range
10 to 50 pF
-
Input voltage
10:1 400V CAT I, 300V CAT II ；1:1 150V CAT I
-
Temperature and humidity
0℃ to 50 ℃；85% RH
-
Overall length
1.2m
-
-
-
Attenuation ratio
10:1 / 1:1
-
Bandwidth
DC to 500MHz
-
Rise time
0.7nS
-
Input impedance
10MΩ / 1MΩ
-
Input capacitance
9 pF / 95 pF
-
Compensation range
10 to 50 pF
-
Input voltage
10:1 400V CAT I, 300V CAT II；1:1 150V CAT I
-
Temperature and humidity
0℃ to 50 ℃；85% RH
-
Overall length
1.2m
-
-
-
Attenuation ratio
10:1/1:1
-
Bandwidth
100MHz
-
Rise time
3.5nS
-
Input impedance
10:1 10MΩ/1:1 1MΩ
-
Input capacitance
95 pF
-
Compensation range
10:1 10 to 50 pF
-
Input voltage
10:1 400V CAT I, 300V CAT II ；1:1 150V CAT I
-
Temperature and humidity
0℃ to 50 ℃；85% RH
-
Overall length
1.2m
-
