Product name
Safety type test lead
-
Rated voltage
1000V CATIII
-
Rated current
10A
-
Contact material
Nickel-plated brass
-
Conductor insulation material
Silicone rubber
-
Wire length
1200mm/Customized
-
Connector A
4mm right-angle male plug
-
Connector B
4mm male plug
-
Color
Red, black, yellow, green and blue
-
-
-
Product name
Direct insertion clamp wire
-
Rated voltage
1000V CATIII
-
Rated current
10A
-
Contact material
Nickel plating on iron
-
Conductor insulation material
Silicone rubber
-
Wire length
180mm/Customized
-
Connector A
4mm straight-in banana plug
-
Connector B
alligator clip
-
Color
Red, black
-
-
-
Product name
Turn the plug to the alligator clip wire
-
Rated voltage
1000V CATIII
-
Rated current
10A
-
Contact material
Nickel-plated brass
-
Conductor insulation material
Silicone rubber
-
Wire length
1200mm/Customized
-
Connector A
4mm right-angle banana plug
-
Connector B
Alligator clip
-
Color
Red, black
-
-
-
Maximum Passing Current
100A
-
Dielectric strength
≤3000VDC
-
Outer diameter of wire
11mm
-
Cross-sectional area of conductor
25mm²
-
Lengths
customizable
-
Color
red black
-
-
-
Maximum Passing Current
40A
-
Dielectric strength
≤3000VDC
-
Outer diameter of wire
6.7mm
-
Cross-sectional area of conductor
10mm²
-
Lengths
customizable
-
Color
red black
-
-
-
Maximum Passing Current
20A
-
Dielectric strength
≤3000VDC
-
Outer diameter of wire
4.3mm
-
Cross-sectional area of conductor
4mm²
-
Lengths
customizable
-
Color
red black
-
-
-
Maximum Passing Current
30A
-
Dielectric strength
≤3000VDC
-
Outer diameter of wire
5.2mm
-
Cross-sectional area of conductor
5.3mm²
-
Lengths
customizable
-
Color
red black
-
-
-
Maximum Passing Current
40A
-
Dielectric strength
≤3000VDC
-
Outer diameter of wire
5.8mm
-
Cross-sectional area of conductor
6mm²
-
Lengths
customizable
-
Color
red black
-
-
-
Maximum Passing Current
50A
-
Dielectric strength
≤3000VDC
-
Outer diameter of wire
6.3mm
-
Cross-sectional area of conductor
8mm²
-
Lengths
customizable
-
Color
red black
-
-
-
Maximum Passing Current
750A
-
Dielectric strength
≤3000VDC
-
Outer diameter of wire
19.6mm
-
Cross-sectional area of conductor
95mm²
-
Lengths
customizable
-
Color
red black
-
